Luyi Split-Type Solar Street Light Head Structure & Assembly Guide
As a split solar street light, the Luyi model separates the solar panel, battery system, and lighting head. This design places higher requirements on the lamp head assembly, as it must ensure stable illumination performance, effective heat management, and long-term outdoor durability.
This video focuses on the assembly of the light head for the Luyi Model Split Solar Street Light, highlighting how the LED module, heat dissipation structure, optical components, and control interfaces are integrated into a compact and durable lighting head.
As a split solar street light, the Luyi model separates the solar panel, battery system, and lighting head. This design places higher requirements on the lamp head assembly, as it must ensure stable illumination performance, effective heat management, and long-term outdoor durability.
This video helps project planners, distributors, and engineers clearly understand how the Luyi split-type street light head is assembled and prepared for field installation.
Assembly Highlights: Designed for Long-Term Road Lighting
The Luyi split solar street light head is assembled following a performance-oriented structure, ensuring consistent lighting output and reduced failure rates during long-term operation.
1. LED Module Installation
-
High-lumen LED chips mounted on precision aluminum substrate
-
Optimized LED layout for uniform road illumination
-
Secure fixation to maintain stable light output over time
2. Heat Dissipation Structure Assembly
-
Integrated aluminum heat sink design
-
Direct thermal contact between LED module and housing
-
Efficient heat transfer to prevent lumen degradation
3. Optical System Integration
-
Professional road-light lens design
-
Controlled beam angle for wider coverage and reduced glare
-
Accurate lens alignment to improve lighting uniformity
4. Control Interface & Wiring Setup
-
Waterproof connectors for external battery and solar panel
-
Clear separation of power and signal lines
-
Organized internal wiring to improve reliability and maintenance efficiency
5. Housing Sealing & Protection
-
Industrial-grade outdoor housing
-
Reinforced sealing structure against dust and rain
-
Designed to withstand long-term exposure to harsh environments
6. Functional Testing
-
LED brightness and uniformity inspection
-
Electrical continuity and stability check
-
Assembly integrity verification before shipment
Technical Specifications (Lamp Head Reference)
| Item | Specification |
|---|---|
| Product Type | Split Solar Street Light |
| Model | Luyi |
| Component | Street Light Head |
| Light Source | High-Brightness LED |
| Luminous Efficiency | ≥ 180 lm/W (Reference) |
| Beam Angle | Road-Type Optical Lens |
| Housing Material | Die-Cast Aluminum |
| Protection Level | IP65 |
| Working Temperature | -20°C to +60°C |
| Installation Method | Arm Mount/Pole Mount |
| Application Height | 5–9 meters |
Key Functions
-
Stable Road Illumination
Provides consistent and uniform lighting for streets and pathways. -
Compatible with Smart Control Systems
Supports light control, time control, and motion-based systems depending on configuration. -
Independent Lamp Head Design
Easier replacement and maintenance compared to all-in-one systems. -
Outdoor-Ready Structure
Designed to operate reliably in rain, dust, and high-temperature environments.
Product Advantages
Improved Heat Management
The separated lamp head structure allows better thermal control, extending LED lifespan.
Higher Lighting Flexibility
The split design supports customized system configurations for different road conditions.
Project-Oriented Design
Ideal for municipal roads, industrial parks, residential streets, and infrastructure projects.
Reduced Maintenance Cost
The lamp head can be serviced independently without dismantling the full system.
Typical Applications
-
• Urban and suburban roads
-
• Residential street lighting
-
• Industrial park roadways
-
• Public infrastructure projects
-
• Customized solar street lighting systems
Why Choose the Luyi Split Solar Street Light from Queneng Lighting
-
•Strong experience in split solar street light manufacturing
-
• Engineering-driven lamp head design
-
• Strict assembly and inspection standards
-
• Support for OEM/ODM project customization
The Luyi split solar street light head is engineered to deliver stable illumination, long service life, and practical maintenance advantages for professional outdoor lighting projects.
